YB80 Single Shaft Vane Pump

YB Series Rotary Vane Pump

Technical Specifications

YB Series Self priming rotary vane pump with internal by-pass valve. The pumps use a rotor with sliding vanes to draw the liquid. The material of construction is nodular iron with sliding vanes built in a special self-lubricating material. Due to its efficiency the pumps can handle viscous and also volatile liquids and require less horsepower than other equivalent pumps. The pumps are capable of higher flow-rates at lower number of revolutions than other designs.

Advantage:

◆ Durable pumps for fast and quiet operation.

◆ Sliding vane design provides sustained performance and trouble free operation, high reliability.

◆ Adjustable relief valve protects pump from excessive pressure.

◆ T-type strainers are available to protect pumping system from damage caused by welding slag and foreign matter in the piping and tanks.

Price :R19,350.00 Excl VAT

Quantity :


Payments Secured by:

Global Delivery by:



SKU: 456132-1 Categories: , Tags: ,

Description

Flow Rate:

Model 650RPM 600RPM 550RPM 500RPM 450RPM 400RPM
G/min L/min G/min L/min G/min L/min G/min L/min G/min L/min G/min L/min
YB-50 50mm/2″ 80 300 72 270 64 240 56 210 48 180 40 150
YB-65 65mm/2″ 132 500 123 456 114 430 103 390 93 350 82 310
YB-80 80mm/3″ 265 1000 243 920 222 840 200 760 180 680 160 600
YB-100 100mm/4″ 505 1900 405 1530

Package size:

Model YB-50 YB-65 YB-80 YB-100
Material Without Motor Without Motor,
V-Belt Driver
Without Motor Without Motor,
V-Belt Driver
Without Motor Without Motor,
V-Belt Driver
Without Motor
Dimension 44×33×39cm 80×55×59cm 44×33×32cm 119×55×59cm 45×40×38cm 130×47.5×76cm 54×49×58cm
Gross Weight 32Kg 90Kg 42.5Kg 110Kg 66Kg 200Kg 172Kg
Net Weight 31Kg 86Kg 40Kg 92Kg 64Kg 185Kg 160Kg
Package 1pc/Wood Case

Performance Data:

Model YB-50 YB-65 YB-80 YB-100
Rated speed 640RPM 640RPM 640RPM 500RPM
HP 3.0 5.0 10 25
KW 2.2 4 7.5 18.5

Additional information

Weight 66 kg
Dimensions 46 × 40 × 38 cm
