Technical Specifications
OGM-25/40/50 aluminium oval gear meter has the ability to handle a wide range of fluid viscosities with exceptional levels of repeatability and durability, applying in the petroleum,chemical,food industry,etc.
Advantage：
Price :R3,250.00 Excl VAT
Technical Data：
| Model： | OGM-A-25 | OGM-A-40 | OGM-A-50 |
| Size： | 1″ | 1 1/2″ | 2″ |
| Min.Flow Rate： | 20L/min | 25L/min | 30L/min |
| Max.Flow Rate： | 120L/min | 250L/min | 300L/min |
| Accueacy： | ±0.5% | ±0.5% | ±0.5% |
| Repeatability： | ≤0.03% | ≤0.03% | ≤0.03% |
| Max.Viscosity： | 1000CPS | 1000CPS | 1000CPS |
| Max.Operating Pressuer： | 3.4MPa | 1.8MPa | 1.8MPa |
Package Data：
| Model | OGM-A-25 | OGM-A-40 |
| Dimension | 40×23×31cm | 49×28×22cm |
| Net Weight | 8kg | 10kg |
| Gross Weight | 9kg | 11kg |
| Package | 4pc/Carton | 2pc/Carton |
| Weight | 3.8 kg |
|---|---|
| Dimensions | 25 × 24 × 21 cm |
